Thermoplastic Granulator




We are a technology-driven Manufacturer and Exporter of Thermoplastic Granulator. Whatever the grinding job, there is clips G series reduction solutions. The result of our rich experience is your advantage in granulating of all thermoplastic materials. Smooth running & low noise level are ensured due to a solid & compact constructed cutting chamber. The cutting blades out of a high- tensile steel are integrated in the router on their whole length and do not need to be adjusted, even after several regrind operations. The real helical cut with a constant gap between rotary & stationary blades causes low dust development & reduces the electrical power consumption. Thermoplastic Granulator is easy to use and ensures less maintenance.


Technical Specifications

Model Blade Length Blade Material No of Bladers Fiexed Moving Power Reqd. Output Kg/Hr Suitable for grinding
Clips G9 9 Dye steel D2 4 2 7.5 Hp 40-50 Small runners, articles etc
Clips G12 12 Dye steel D 2 4 2 10 Hp 60-70 Runners & injection/blow moulded containers upto 2 ltrs with flash
Clips G15 15 Dye steel D 2 4 2 15 Hp 120-150 Injection molded articles & blow moulded containers upto 5ltrs. With flash, thermoforming waste etc.
Clips G18 18 Dye steel D 2 4 2 15 Hp 180-200 Medium Size articles & containers upto 12 ltrs, with flash, thermoforming waste, pet waste
Clips G20 20 Dye steel D 2 4 2 25Hp + 3 HP 220-300 Injection moulded articles, pvc pipe fittings, profiles & blow moulded containers upto 20 ltrs. With flash, thermoforming waste, pet wast etc.
Clips G24 24 Dye steel D 2 4 2 30 Hp + 5 HP 250-400 Injection moulded articles, pvc pipe fittings, profiles & blow moulded containers upto 40 ltrs. With flash, themoforming waste, pet waste etc.
